VOTO - VOTE ADVICE APPLICATION API (0.0.1)

Download OpenAPI specification:Download

API Support: help@voto.vote URL: https://voto.vote/ License: MIT

Defines a common interface for vote advice applications

To secure the API, we use different roles within our system. The following table shows the permissions of each role for each entity. It does not reflect reality perfectly. Creator can obviously only create candidates for its own application etc, but the table should give you an idea of how the roles work.

	Admin	Creator	TrustPerson	Candidate	Anonymous
Election	CRUD	R	R	R	R
Candidate	CRUD	CRUD	CRUD	RU	R
CandidateVotes	CRUD	CRUD	CRUD	RU	R
Party	CRUD	CRUD	RU	R	R
PartyVotes	CRUD	CRUD	RU	R	R
Application	CRUD	CRUD	R	R	R
Theses	CRUD	CRUD	R	R	R
Votings	R	CR	CRU	CRU	CR
Trustperson	CRUD	CRUD	CRUD	R	-
Creator	CRUD	CRUD	R	R	-
Admins	CRUD	R	-	-	-
Users	CRUD	CR	CR	RUD	-

C = Create
R = Read
U = Update
D = Delete

Authentication

firebase

We currently use Firebase as Authentication Provider. In order to use parts of the API, you have to have a valid account and role. Retrieve this idToken here https://firebase.google.com/docs/reference/rest/auth#section-sign-in-email-password

Security Scheme Type	HTTP
HTTP Authorization Scheme	bearer
Bearer format	"JWT"

Election

Objects related to elections

Fetches array of Elections

Fetching elections is allowed for the creator and admin role.

Authorizations:

firebase

query Parameters

limit	integer Default: 20 Example: limit=20 Limits the amount of items in the responsing array. Max results is 100.
page	integer Default: 1 Example: page=5 Sets the page offset
search	string Default: "" Example: search=Bundestagswahl Search for election name
sort	string Default: "name\|asc" Example: sort=location\|desc Sort either ascending or descending all retrieving objects. Always like {attribute}\|{sortingOrder} where sortingOrder can be either `asc` or `desc`

Responses

Response samples

200
401
403
500

Content type

application/json

{"data": [{"election_date": "2021-09-26",
"location": "Deutschland",
"name": "Bundestagswahl",
"status": 0,
"id": 123,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}
],
"pagination": {"total": 100,
"per_page": 20,
"current_page": 1,
"last_page": 4,
"from": 1,
"to": 19,
"_links": {"self": "https://api.voto.vote/{entity+}?page=1",
"prev": "https://api.voto.vote/{entity+}?page=0",
"next": "https://api.voto.vote/{entity+}?page=2"
}
}
}

Create Election object

Creating elections is allowed for the admin role.

Authorizations:

firebase

Request Body schema: application/json

election_date	string <date>
location	string
name	string

Responses

Request samples

Payload

Content type

application/json

{"election_date": "2021-09-26",
"location": "Deutschland",
"name": "Bundestagswahl"
}

Response samples

201
400
401
403
500

Content type

application/json

{"election_date": "2021-09-26",
"location": "Deutschland",
"name": "Bundestagswahl",
"status": 0,
"id": 123,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}

Get single Election

Fetching one single election by its ID is allowed for everyone.

path Parameters

electionId

required

integer <int64>

Numeric ID of the election to get

Responses

Response samples

200
404
500

Content type

application/json

{"election_date": "2021-09-26",
"location": "Deutschland",
"name": "Bundestagswahl",
"status": 0,
"id": 123,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}

Update Election object

Updating one single election by its ID is allowed for the admin role.

Authorizations:

firebase

path Parameters

electionId

required

integer <int64>

Numeric ID of the election to put

Request Body schema: application/json

election_date	string <date>
location	string
name	string

Responses

Request samples

Payload

Content type

application/json

{"election_date": "2021-09-26",
"location": "Deutschland",
"name": "Bundestagswahl"
}

Response samples

Content type

application/json

{"election_date": "2021-09-26",
"location": "Deutschland",
"name": "Bundestagswahl",
"status": 0,
"id": 123,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}

Delete Election object

Deleting one single election by its ID is allowed for the admin role.

Authorizations:

firebase

path Parameters

electionId

required

integer <int64>

Numeric ID of the election to delete

Responses

Response samples

401
403
404
500

Content type

application/json

{"code": "400",
"message": "Malformed request"
}

Fetches array of applications for one specific instance

Fetching applications is for one specific election is only allowed for the admin role.

Authorizations:

firebase

path Parameters

electionId

required

integer

Example: 1

Defines the election

query Parameters

limit	integer Default: 20 Example: limit=20 Limits the amount of items in the responsing array. Max results is 100.
page	integer Default: 1 Example: page=5 Sets the page offset
search	string Default: "" Example: search=Bundestagswahl Search for application title
sort	string Default: "name\|asc" Example: sort=location\|desc Sort either ascending or descending all retrieving objects. Always like {attribute}\|{sortingOrder} where sortingOrder can be either `asc` or `desc`

Responses

Response samples

200
401
403
500

Content type

application/json

{"data": [{"election_id": 123,
"cluster_id": 456,
"theme_id": 789,
"title": "Example Title",
"subtitle": "Example Subtitle",
"description": "Lorem ipsum dolor sed amet.",
"website": "https://voto.vote",
"url": "https://foo.bar/vaa",
"launch_date": "2021-10-05T06:00:00.000Z",
"sundown_date": "2021-10-05T06:00:00.000Z",
"configuration": "https://voto.vote/foo_bar.json",
"id": 123,
"status": 123,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}
],
"pagination": {"total": 100,
"per_page": 20,
"current_page": 1,
"last_page": 4,
"from": 1,
"to": 19,
"_links": {"self": "https://api.voto.vote/{entity+}?page=1",
"prev": "https://api.voto.vote/{entity+}?page=0",
"next": "https://api.voto.vote/{entity+}?page=2"
}
}
}

Fetches array of timeline entries

Authorizations:

firebase

Responses

Response samples

200
400
500

Content type

application/json

[{"election_date": "2024-07-14",
"applications": [{"id": 123,
"title": "Example Title",
"url": "https://app.voto.vote/neubrandenburg",
"background": "https://votoprod.appspot.com.storage.googleapis.com/configuration/1626736/blob"
}
]
}
]

VAA

Objects related to Vote advice applications

Fetches array of VAA's

Fetching applications is allowed for admin

Authorizations:

firebase

query Parameters

limit	integer Default: 20 Example: limit=20 Limits the amount of items in the responsing array. Max results is 100.
page	integer Default: 1 Example: page=5 Sets the page offset
search	string Default: "" Example: search=VOTO Search for application title
sort	string Default: "name\|asc" Example: sort=location\|desc Sort either ascending or descending all retrieving objects. Always like {attribute}\|{sortingOrder} where sortingOrder can be either `asc` or `desc`

Responses

Response samples

200
401
403
500

Content type

application/json

{"data": [{"election_id": 123,
"cluster_id": 456,
"theme_id": 789,
"title": "Example Title",
"subtitle": "Example Subtitle",
"description": "Lorem ipsum dolor sed amet.",
"website": "https://voto.vote",
"url": "https://foo.bar/vaa",
"launch_date": "2021-10-05T06:00:00.000Z",
"sundown_date": "2021-10-05T06:00:00.000Z",
"configuration": "https://voto.vote/foo_bar.json",
"id": 123,
"status": 123,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}
],
"pagination": {"total": 100,
"per_page": 20,
"current_page": 1,
"last_page": 4,
"from": 1,
"to": 19,
"_links": {"self": "https://api.voto.vote/{entity+}?page=1",
"prev": "https://api.voto.vote/{entity+}?page=0",
"next": "https://api.voto.vote/{entity+}?page=2"
}
}
}

Create VAA object

Creating applications is allowed for admin

Authorizations:

firebase

Request Body schema: application/json

election_id required	integer
cluster_id required	integer
theme_id	integer
title required	string
subtitle	string
description	string
website	string
url	string
launch_date	string <date-time>
sundown_date	string <date-time>
configuration	string This is the url, where you find your individual configuration for the VOTO VAA

Responses

Request samples

Payload

Content type

application/json

{"election_id": 123,
"cluster_id": 456,
"theme_id": 789,
"title": "Example Title",
"subtitle": "Example Subtitle",
"description": "Lorem ipsum dolor sed amet.",
"website": "https://voto.vote",
"url": "https://foo.bar/vaa",
"launch_date": "2021-10-05T06:00:00.000Z",
"sundown_date": "2021-10-05T06:00:00.000Z",
"configuration": "https://voto.vote/foo_bar.json"
}

Response samples

201
400
401
403
500

Content type

application/json

{"election_id": 123,
"cluster_id": 456,
"theme_id": 789,
"title": "Example Title",
"subtitle": "Example Subtitle",
"description": "Lorem ipsum dolor sed amet.",
"website": "https://voto.vote",
"url": "https://foo.bar/vaa",
"launch_date": "2021-10-05T06:00:00.000Z",
"sundown_date": "2021-10-05T06:00:00.000Z",
"configuration": "https://voto.vote/foo_bar.json",
"id": 123,
"status": 123,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}

Fetches array of clusters

Fetching clusters is allowed for admin

Authorizations:

firebase

Responses

Response samples

200
401
403
500

Content type

application/json

[{"title": "Example Title",
"subtitle": "Example Subtitle",
"description": "Lorem ipsum dolor sed amet.",
"url": "https://foo.bar/cluster",
"id": 123,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}
]

Create Cluster object

Creating clusters is allowed for admin

Authorizations:

firebase

Request Body schema: application/json

title required	string
subtitle	string
description	string
url	string

Responses

Request samples

Payload

Content type

application/json

{"title": "Example Title",
"subtitle": "Example Subtitle",
"description": "Lorem ipsum dolor sed amet.",
"url": "https://foo.bar/cluster"
}

Response samples

201
400
401
403
500

Content type

application/json

{"title": "Example Title",
"subtitle": "Example Subtitle",
"description": "Lorem ipsum dolor sed amet.",
"url": "https://foo.bar/cluster",
"id": 123,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}

Fetches single cluster

Fetching one cluster is allowed for everyone

path Parameters

clusterId

required

integer <int64>

Numeric ID of the Cluster

Responses

Response samples

200
404
500

Content type

application/json

{"title": "Example Title",
"subtitle": "Example Subtitle",
"description": "Lorem ipsum dolor sed amet.",
"url": "https://foo.bar/cluster",
"id": 123,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}

Update Cluster object

Updating one cluster is allowed for admin and creator (for its own applications)

Authorizations:

firebase

path Parameters

clusterId

required

integer <int64>

Numeric ID of the Cluster

Request Body schema: application/json

title required	string
subtitle	string
description	string
url	string

Responses

Request samples

Payload

Content type

application/json

{"title": "Example Title",
"subtitle": "Example Subtitle",
"description": "Lorem ipsum dolor sed amet.",
"url": "https://foo.bar/cluster"
}

Response samples

Content type

application/json

{"title": "Example Title",
"subtitle": "Example Subtitle",
"description": "Lorem ipsum dolor sed amet.",
"url": "https://foo.bar/cluster",
"id": 123,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}

Remove Cluster object

Updating one cluster is allowed for admins

Authorizations:

firebase

path Parameters

clusterId

required

integer <int64>

Numeric ID of the Cluster

Request Body schema: application/json

title required	string
subtitle	string
description	string
url	string

Responses

Request samples

Payload

Content type

application/json

{"title": "Example Title",
"subtitle": "Example Subtitle",
"description": "Lorem ipsum dolor sed amet.",
"url": "https://foo.bar/cluster"
}

Response samples

400
401
403
404
500

Content type

application/json

{"code": "400",
"message": "Malformed request"
}

Fetches single VAA

Fetching one application is allowed for everyone

path Parameters

applicationId

required

integer <int64>

Numeric ID of the VAA

Responses

Response samples

200
404
500

Content type

application/json

{"election_id": 123,
"cluster_id": 456,
"theme_id": 789,
"title": "Example Title",
"subtitle": "Example Subtitle",
"description": "Lorem ipsum dolor sed amet.",
"website": "https://voto.vote",
"url": "https://foo.bar/vaa",
"launch_date": "2021-10-05T06:00:00.000Z",
"sundown_date": "2021-10-05T06:00:00.000Z",
"configuration": "https://voto.vote/foo_bar.json",
"id": 123,
"status": 123,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}

Update VAA object

Updating one application is allowed for admin and creator (for its own applications)

Authorizations:

firebase

path Parameters

applicationId

required

integer <int64>

Numeric ID of the VAA

Request Body schema: application/json

election_id required	integer
cluster_id required	integer
theme_id	integer
title required	string
subtitle	string
description	string
website	string
url	string
launch_date	string <date-time>
sundown_date	string <date-time>
configuration	string This is the url, where you find your individual configuration for the VOTO VAA

Responses

Request samples

Payload

Content type

application/json

{"election_id": 123,
"cluster_id": 456,
"theme_id": 789,
"title": "Example Title",
"subtitle": "Example Subtitle",
"description": "Lorem ipsum dolor sed amet.",
"website": "https://voto.vote",
"url": "https://foo.bar/vaa",
"launch_date": "2021-10-05T06:00:00.000Z",
"sundown_date": "2021-10-05T06:00:00.000Z",
"configuration": "https://voto.vote/foo_bar.json"
}

Response samples

Content type

application/json

{"election_id": 123,
"cluster_id": 456,
"theme_id": 789,
"title": "Example Title",
"subtitle": "Example Subtitle",
"description": "Lorem ipsum dolor sed amet.",
"website": "https://voto.vote",
"url": "https://foo.bar/vaa",
"launch_date": "2021-10-05T06:00:00.000Z",
"sundown_date": "2021-10-05T06:00:00.000Z",
"configuration": "https://voto.vote/foo_bar.json",
"id": 123,
"status": 123,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}

Delete VAA object

Deleting one application is allowed for admin and creator (for its own applications)

Authorizations:

firebase

path Parameters

applicationId

required

integer <int64>

Numeric ID of the VAA

Responses

Response samples

401
403
404
500

Content type

application/json

{"code": "400",
"message": "Malformed request"
}

Fetches the configuration of the application

Fetching one applications config is allowed for everyone

path Parameters

applicationId

required

integer <int64>

Numeric ID of the VAA

Responses

Response samples

200
404

Content type

application/json

{"introduction": {"background": "voto://configuration/default/bg1.jpg"
},
"sponsors": [{"name": "string",
"image": "string",
"href": "string"
}
],
"cluster": {"instances": [123
],
"title": "Cluster title",
"description": "Cluster description"
},
"ads": {"html": "string",
"link": "string",
"theme": "string"
}
}

Update the configuration of the application

Fetching one applications config is allowed for everyone

path Parameters

applicationId

required

integer <int64>

Numeric ID of the VAA

Request Body schema: multipart/form-data

configuration

string <binary>

Responses

Response samples

200
400

Content type

application/json

{"introduction": {"background": "voto://configuration/default/bg1.jpg"
},
"sponsors": [{"name": "string",
"image": "string",
"href": "string"
}
],
"cluster": {"instances": [123
],
"title": "Cluster title",
"description": "Cluster description"
},
"ads": {"html": "string",
"link": "string",
"theme": "string"
}
}

Upload image to configuration of the application

Upload one applications config is allowed for everyone

path Parameters

applicationId

required

integer <int64>

Numeric ID of the VAA

Responses

Response samples

400
404

Content type

application/json

{"code": "400",
"message": "Malformed request"
}

Delete an image of the configuration of the application

Deleting one applications config images is allowed for admins and creator of this application

path Parameters

applicationId

required

integer <int64>

Numeric ID of the VAA

Request Body schema: multipart/form-data

name

string

Responses

Response samples

400

Content type

application/json

{"code": "400",
"message": "Malformed request"
}

Fetches all theses for one VAA regardless of the language

Fetching one applications theses is allowed for everyone

path Parameters

applicationId

required

integer <int64>

Numeric ID of the VAA

Responses

Response samples

200
400
500

Content type

application/json

[{"lamguage": "de",
"theses": [{"title": "Lorem ipsum dolor sed amet",
"text": "Lorem ipsum dolor sed amet",
"statement_id": 123,
"translation_id": 123,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}
]
}
]

Fetches all available languages for theses for one VAA regardless of the language

Fetching all available languages of theses is allowed for everyone

path Parameters

applicationId

required

integer <int64>

Numeric ID of the VAA

Responses

Response samples

200
400
500

Content type

application/json

["de"
]

Fetches all theses for one VAA

Fetching one applications theses is allowed for everyone

path Parameters

applicationId required	integer <int64> Numeric ID of the VAA
language required	string Default: "" Example: de Language identification string, e.g. 'de'

Responses

Response samples

200
404
500

Content type

application/json

[{"title": "Lorem ipsum dolor sed amet",
"text": "Lorem ipsum dolor sed amet",
"statement_id": 123,
"translation_id": 123,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}
]

Add these

Adding application theses is allowed for admin and creator (for its own applications)

Authorizations:

firebase

path Parameters

applicationId required	integer <int64> Numeric ID of the VAA
language required	string Default: "" Example: de Language identification string, e.g. 'de'

Request Body schema: application/json

title	string
text	string <text>

Responses

Request samples

Payload

Content type

application/json

{"title": "Lorem ipsum...",
"text": "Lorem ipsum dolor sed amet"
}

Response samples

Content type

application/json

{"title": "Lorem ipsum dolor sed amet",
"text": "Lorem ipsum dolor sed amet",
"statement_id": 123,
"translation_id": 123,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}

Fetches single these of one VAA

Fetching one applications these is allowed for everyone

path Parameters

applicationId required	integer <int64> Numeric ID of the VAA
language required	string Default: "" Example: de Language identification string, e.g. 'de'
theseId required	integer <int64> Example: 123 Numeric ID of the these

Responses

Response samples

200
404
500

Content type

application/json

{"title": "Lorem ipsum dolor sed amet",
"text": "Lorem ipsum dolor sed amet",
"statement_id": 123,
"translation_id": 123,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}

Update single these

Updating application theses is allowed for admin and creator (for its own applications)

Authorizations:

firebase

path Parameters

applicationId required	integer <int64> Numeric ID of the VAA
language required	string Default: "" Example: de Language identification string, e.g. 'de'
theseId required	integer <int64> Numeric ID of the these

Request Body schema: application/json

title	string
text	string <text>

Responses

Request samples

Payload

Content type

application/json

{"title": "Lorem ipsum...",
"text": "Lorem ipsum dolor sed amet"
}

Response samples

Content type

application/json

{"title": "Lorem ipsum dolor sed amet",
"text": "Lorem ipsum dolor sed amet",
"statement_id": 123,
"translation_id": 123,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}

Add translation for specific these

Adding translation for specific these is allowed for admin and creator (for its own applications)

Authorizations:

firebase

path Parameters

applicationId required	integer <int64> Numeric ID of the VAA
language required	string Default: "" Example: de Language identification string, e.g. 'de'
theseId required	integer <int64> Numeric ID of the these - not the translation, but the statementID !

Request Body schema: application/json

statement_id	integer <int64> identifies the statement id
title	string
text	string <text>

Responses

Request samples

Payload

Content type

application/json

{"statement_id": 123,
"title": "Lorem ipsum...",
"text": "Lorem ipsum dolor sed amet"
}

Response samples

Content type

application/json

{"title": "Lorem ipsum dolor sed amet",
"text": "Lorem ipsum dolor sed amet",
"statement_id": 123,
"translation_id": 123,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}

Delete specific these of application

Deleting a specific these for one application is allowed for admin, creator (within his application)

Authorizations:

firebase

path Parameters

applicationId required	integer <int64> Numeric ID of the application
language required	integer <int64> Language identification string, e.g. 'de'
theseId required	integer <int64> Numeric ID of the these

Responses

Response samples

401
403
404
500

Content type

application/json

{"code": "400",
"message": "Malformed request"
}

Create new custom event for application

Authorizations:

firebase

Request Body schema: application/json

Array ()

integer

Responses

Request samples

Payload

Content type

application/json

[0
]

Response samples

400
401
403
500

Content type

application/json

{"code": "400",
"message": "Malformed request"
}

API

About this API

Get info about this API

query Parameters

version

string

Example: version=v1

Version of API

Responses

Vote

Endpoints for everything vote related

Submit a new voting for an VAA

Creation of votings is allowed for everyone. Please note, that we still prevent CORS requests.

Request Body schema: application/json

Array of objects

Responses

Request samples

Payload

Content type

application/json

{"votes": [{"statement_id": 123,
"application_id": 456,
"value": 75,
"weight": 1,
"explanation": "Lorem ipsum"
}
]
}

Response samples

201
400
500

Content type

application/json

{"votes": [{"statement_id": 123,
"application_id": 456,
"value": 75,
"weight": 1,
"explanation": "Lorem ipsum"
}
],
"id": 123,
"application_id": 456,
"matches": [{"match": {"party_id": 123,
"description": "Example Title",
"district": "Example District",
"list_place": 1,
"website": "https://voto.vote",
"id": 123,
"application_id": 789,
"title": "Dr.",
"firstName": "John",
"lastName": "Doe",
"age": 456,
"party_name": "VOP",
"profile_picture": "https://",
"status": 1,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z",
"public": false
},
"match_type": "candidate",
"score": 99.7
}
],
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}

Roles

Management endpoints for roles within the VOTO platform. Please note, that candidates are handled in /elections endpoints as they are the only entity which is directly related to a match, whereas a party can have multiple TrustPersons

Get admins

Fetching admins is allowed for admins

query Parameters

limit	integer Default: 20 Example: limit=20 Limits the amount of items in the responsing array. Max results is 100.
page	integer Default: 1 Example: page=5 Sets the page offset
search	string Default: "" Example: search=admins mail Search for admins email
sort	string Default: "name\|asc" Example: sort=location\|desc Sort either ascending or descending all retrieving objects. Always like {attribute}\|{sortingOrder} where sortingOrder can be either `asc` or `desc`

Responses

Response samples

200
401
403
404
500

Content type

application/json

{"data": [{"user_id": 123,
"id": 123,
"firstName": "John",
"lastName": "Doe",
"contact": "john@doe.com",
"status": 1,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}
],
"pagination": {"total": 100,
"per_page": 20,
"current_page": 1,
"last_page": 4,
"from": 1,
"to": 19,
"_links": {"self": "https://api.voto.vote/{entity+}?page=1",
"prev": "https://api.voto.vote/{entity+}?page=0",
"next": "https://api.voto.vote/{entity+}?page=2"
}
}
}

Create new admin

Creation of admins is allowed for admins

Request Body schema: application/json

user_id

integer <int64>

user_id which should be promoted to an admin

Responses

Request samples

Payload

Content type

application/json

{"user_id": 123
}

Response samples

Content type

application/json

{"user_id": 123,
"id": 123,
"firstName": "John",
"lastName": "Doe",
"contact": "john@doe.com",
"status": 1,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}

Get Admin by ID

Fetching admins is allowed for admins

path Parameters

adminId

required

integer <int64>

Numeric ID of the admin

Responses

Response samples

200
401
403
404
500

Content type

application/json

{"user_id": 123,
"id": 123,
"firstName": "John",
"lastName": "Doe",
"contact": "john@doe.com",
"status": 1,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}

Remove admin

Remove admin is allowed for admin

path Parameters

adminId

required

integer <int64>

Numeric ID of the admin

Responses

Response samples

401
403
404
500

Content type

application/json

{"code": "400",
"message": "Malformed request"
}

Create new user

Creation of users is allowed for admins, creators, and trustpersons

Request Body schema: application/json

title	string
first_name required	string
last_name required	string
gender_id required	integer <int64>
email required	string <email>
birthday	string <date>
phone	integer
address1	string
address2	string
job	string
zipcode	integer
city	string
status	integer <int64> Status of user

Responses

Request samples

Payload

Content type

application/json

{"title": "Dr.",
"first_name": "John",
"last_name": "Doe",
"gender_id": 123,
"email": "john@doe.com",
"birthday": "1993-12-27",
"phone": 1234567890,
"address1": "Johnstreet 42",
"address2": "2nd floor",
"job": "CEO",
"zipcode": 12345,
"city": "Stuttgart",
"status": 1
}

Response samples

Content type

application/json

{"title": "Dr.",
"first_name": "John",
"last_name": "Doe",
"gender_id": 123,
"email": "john@doe.com",
"birthday": "1993-12-27",
"phone": 1234567890,
"address1": "Johnstreet 42",
"address2": "2nd floor",
"job": "CEO",
"zipcode": 12345,
"city": "Stuttgart",
"status": 1,
"id": 123,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}

Get User by ID

Fetching users is allowed for admins

path Parameters

userId

required

integer <int64>

Numeric ID of the user

Responses

Response samples

200
401
403
404
500

Content type

application/json

{"title": "Dr.",
"first_name": "John",
"last_name": "Doe",
"gender_id": 123,
"email": "john@doe.com",
"birthday": "1993-12-27",
"phone": 1234567890,
"address1": "Johnstreet 42",
"address2": "2nd floor",
"job": "CEO",
"zipcode": 12345,
"city": "Stuttgart",
"status": 1,
"id": 123,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}

Update user

Updating user is allowed for admins and the user itself.

path Parameters

userId

required

integer <int64>

Numeric ID of the VAA

Request Body schema: application/json

title	string
first_name required	string
last_name required	string
gender_id required	integer <int64>
email required	string <email>
birthday	string <date>
phone	integer
address1	string
address2	string
job	string
zipcode	integer
city	string
status	integer <int64> Status of user

Responses

Request samples

Payload

Content type

application/json

{"title": "Dr.",
"first_name": "John",
"last_name": "Doe",
"gender_id": 123,
"email": "john@doe.com",
"birthday": "1993-12-27",
"phone": 1234567890,
"address1": "Johnstreet 42",
"address2": "2nd floor",
"job": "CEO",
"zipcode": 12345,
"city": "Stuttgart",
"status": 1
}

Response samples

Content type

application/json

{"title": "Dr.",
"first_name": "John",
"last_name": "Doe",
"gender_id": 123,
"email": "john@doe.com",
"birthday": "1993-12-27",
"phone": 1234567890,
"address1": "Johnstreet 42",
"address2": "2nd floor",
"job": "CEO",
"zipcode": 12345,
"city": "Stuttgart",
"status": 1,
"id": 123,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}

Change user password or mail

path Parameters

userId

required

integer <int64>

Numeric ID of the user

Request Body schema: application/json

action required	string Enum: "email" "password"
value required	string The value for either the new password or the new mail

Responses

Request samples

Payload

Content type

application/json

{"action": "email",
"value": "newmail@voto.vote"
}

Response samples

401
403
404
500

Content type

application/json

{"code": "400",
"message": "Malformed request"
}

Remove user

Remove user is allowed for admin

path Parameters

userId

required

integer <int64>

Numeric ID of the user

Responses

Response samples

401
403
404
500

Content type

application/json

{"code": "400",
"message": "Malformed request"
}

Invite user

Inviting users is allowed for admins, creator and trustpersons

Request Body schema: application/json

mail

required

string

Responses

Request samples

Payload

Content type

application/json

{"mail": "foo@bar.com"
}

Response samples

Content type

application/json

{"UserId": 1,
"New": true
}

Get your user profile

Fetching yourself is allowed for everyone for their account

Responses

Response samples

200
404
500

Content type

application/json

{"User": {"title": "Dr.",
"first_name": "John",
"last_name": "Doe",
"gender_id": 123,
"email": "john@doe.com",
"birthday": "1993-12-27",
"phone": 1234567890,
"address1": "Johnstreet 42",
"address2": "2nd floor",
"job": "CEO",
"zipcode": 12345,
"city": "Stuttgart",
"status": 1,
"id": 123,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
},
"Creator": {"Id": 1,
"Title": "string",
"LaunchDate": "1993-12-27"
},
"TrustPerson": {"Id": 1,
"Title": "string",
"LaunchDate": "1993-12-27"
},
"Candidate": {"Id": 1,
"Title": "string",
"LaunchDate": "1993-12-27"
},
"Candidates": [{"Id": 1,
"ApplicationId": 1
}
],
"TrustPersons": [{"Id": 1,
"ShortName": "string",
"DetailedName": "string",
"TrustPersonId": 1,
"ApplicationId": 1
}
]
}

Get creator for VAA

Fetching creator is allowed for admins and creator.

path Parameters

applicationId

required

integer <int64>

Numeric ID of the VAA

query Parameters

limit	integer Default: 20 Example: limit=20 Limits the amount of items in the responsing array. Max results is 100.
page	integer Default: 1 Example: page=5 Sets the page offset
search	string Default: "" Example: search=creators mail Search for creators email
sort	string Default: "name\|asc" Example: sort=location\|desc Sort either ascending or descending all retrieving objects. Always like {attribute}\|{sortingOrder} where sortingOrder can be either `asc` or `desc`

Responses

Response samples

200
401
403
404
500

Content type

application/json

{"data": [{"user_id": 123,
"id": 123,
"application_id": 456,
"firstName": "John",
"lastName": "Doe",
"contact": "john@doe.com",
"status": 1,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}
],
"pagination": {"total": 100,
"per_page": 20,
"current_page": 1,
"last_page": 4,
"from": 1,
"to": 19,
"_links": {"self": "https://api.voto.vote/{entity+}?page=1",
"prev": "https://api.voto.vote/{entity+}?page=0",
"next": "https://api.voto.vote/{entity+}?page=2"
}
}
}

Create new creator for VAA

Creation of creator is allowed for admins and creator.

path Parameters

applicationId

required

integer <int64>

Numeric ID of the VAA

Request Body schema: application/json

user_id

integer <int64>

Responses

Request samples

Payload

Content type

application/json

{"user_id": 123
}

Response samples

Content type

application/json

{"user_id": 123,
"id": 123,
"application_id": 456,
"firstName": "John",
"lastName": "Doe",
"contact": "john@doe.com",
"status": 1,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}

Get creator by ID for VAA

Fetching creator is allowed for admins and creator.

path Parameters

applicationId required	integer <int64> Numeric ID of the VAA
creatorId required	integer <int64> Numeric ID of the creator

Responses

Response samples

200
401
403
404
500

Content type

application/json

{"user_id": 123,
"id": 123,
"application_id": 456,
"firstName": "John",
"lastName": "Doe",
"contact": "john@doe.com",
"status": 1,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}

Toggle creator status

Toggle creator is allowed for admins

path Parameters

applicationId required	integer <int64> Numeric ID of the VAA
creatorId required	integer <int64> Numeric ID of the creator

Request Body schema: application/json

status

integer <int64>

Responses

Request samples

Payload

Content type

application/json

{"status": 123
}

Response samples

401
403
404
500

Content type

application/json

{"code": "400",
"message": "Malformed request"
}

Remove creator for VAA

Remove creator is allowed for admins and creator (for its own application).

path Parameters

applicationId required	integer <int64> Numeric ID of the VAA
creatorId required	integer <int64> Numeric ID of the creator

Responses

Response samples

401
403
404
500

Content type

application/json

{"code": "400",
"message": "Malformed request"
}

Get trustpersons for VAA

Fetching trustpersons is allowed for admins and creator as well as for trustpersons for their own party.

path Parameters

applicationId

required

integer <int64>

Numeric ID of the VAA

query Parameters

limit	integer Default: 20 Example: limit=20 Limits the amount of items in the responsing array. Max results is 100.
page	integer Default: 1 Example: page=5 Sets the page offset
search	string Default: "" Example: search=trustpersons mail Search for trustpersons email
sort	string Default: "name\|asc" Example: sort=location\|desc Sort either ascending or descending all retrieving objects. Always like {attribute}\|{sortingOrder} where sortingOrder can be either `asc` or `desc`

Responses

Response samples

200
401
403
404
500

Content type

application/json

{"data": [{"user_id": 123,
"party_id": 456,
"id": 123,
"application_id": 456,
"firstName": "John",
"lastName": "Doe",
"contact": "john@doe.com",
"party_name": "VOP",
"status": 1,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}
],
"pagination": {"total": 100,
"per_page": 20,
"current_page": 1,
"last_page": 4,
"from": 1,
"to": 19,
"_links": {"self": "https://api.voto.vote/{entity+}?page=1",
"prev": "https://api.voto.vote/{entity+}?page=0",
"next": "https://api.voto.vote/{entity+}?page=2"
}
}
}

Create new trustperson for VAA

Creation of trustperson is allowed for admins and creator as well as for trustpersons for their own party.

path Parameters

applicationId

required

integer <int64>

Numeric ID of the VAA

Request Body schema: application/json

user_id	integer <int64>
party_id	integer <int64>

Responses

Request samples

Payload

Content type

application/json

{"user_id": 123,
"party_id": 456
}

Response samples

Content type

application/json

{"user_id": 123,
"party_id": 456,
"id": 123,
"application_id": 456,
"firstName": "John",
"lastName": "Doe",
"contact": "john@doe.com",
"party_name": "VOP",
"status": 1,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}

Get trustperson by ID for VAA

Fetching trustperson by id is allowed for admins and creator.

path Parameters

applicationId required	integer <int64> Numeric ID of the VAA
trustPersonId required	integer <int64> Numeric ID of the trustperson

Responses

Response samples

200
401
403
404
500

Content type

application/json

{"user_id": 123,
"party_id": 456,
"id": 123,
"application_id": 456,
"firstName": "John",
"lastName": "Doe",
"contact": "john@doe.com",
"party_name": "VOP",
"status": 1,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}

Toggle trustperson status

Toggle trustpersons is allowed for admins and creators ( their own application )

path Parameters

applicationId required	integer <int64> Numeric ID of the VAA
trustPersonId required	integer <int64> Numeric ID of the trustperson

Request Body schema: application/json

status

integer <int64>

Responses

Request samples

Payload

Content type

application/json

{"status": 123
}

Response samples

401
403
404
500

Content type

application/json

{"code": "400",
"message": "Malformed request"
}

Remove TrustPerson for VAA

Remove TrustPerson is allowed for admins and creator (for its own application).

path Parameters

applicationId required	integer <int64> Numeric ID of the VAA
trustPersonId required	integer <int64> Numeric ID of the trustperson

Responses

Response samples

400
401
403
404
500

Content type

application/json

{"code": "400",
"message": "Malformed request"
}

Get trustperson by ID for VAA and party

Fetching trustperson by id and party is allowed for admins and creator as well as the trustpersons for this party

path Parameters

applicationId required	integer <int64> Numeric ID of the VAA
trustPersonId required	integer <int64> Numeric ID of the trustperson
partyId required	integer <int64> Numeric ID of the party

Responses

Response samples

200
401
403
404
500

Content type

application/json

{"user_id": 123,
"party_id": 456,
"id": 123,
"application_id": 456,
"firstName": "John",
"lastName": "Doe",
"contact": "john@doe.com",
"party_name": "VOP",
"status": 1,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}

Toggle trustperson status

Toggle trustpersons is allowed for admins and creators ( their own application ) and trustpersons ( their own party )

path Parameters

applicationId required	integer <int64> Numeric ID of the VAA
trustPersonId required	integer <int64> Numeric ID of the trustperson
partyId required	integer <int64> Numeric ID of the party

Request Body schema: application/json

status

integer <int64>

Responses

Request samples

Payload

Content type

application/json

{"status": 123
}

Response samples

401
403
404
500

Content type

application/json

{"code": "400",
"message": "Malformed request"
}

Remove TrustPerson for VAA

Remove TrustPerson is allowed for admins and creator (for its own application) and for trustpersons ( for its own party ).

path Parameters

applicationId required	integer <int64> Numeric ID of the VAA
trustPersonId required	integer <int64> Numeric ID of the trustperson
partyId required	integer <int64> Numeric ID of the party

Responses

Response samples

400
401
403
404
500

Content type

application/json

{"code": "400",
"message": "Malformed request"
}

VAA/Matches

Get candidates for application

Fetching candidates for one single application by its ID is allowed for everyone.

path Parameters

applicationId

required

integer <int64>

Numeric ID of the application to get

query Parameters

limit	integer Default: 20 Example: limit=20 Limits the amount of items in the responsing array. Max results is 100.
page	integer Default: 1 Example: page=5 Sets the page offset
search	string Default: "" Example: search=Mustermann Search for candidate last name
sort	string Default: "name\|asc" Example: sort=location\|desc Sort either ascending or descending all retrieving objects. Always like {attribute}\|{sortingOrder} where sortingOrder can be either `asc` or `desc`

Responses

Response samples

200
404
500

Content type

application/json

{"data": [{"party_id": 123,
"description": "Example Title",
"district": "Example District",
"list_place": 1,
"website": "https://voto.vote",
"id": 123,
"application_id": 789,
"title": "Dr.",
"firstName": "John",
"lastName": "Doe",
"age": 456,
"party_name": "VOP",
"profile_picture": "https://",
"status": 1,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z",
"public": false
}
],
"pagination": {"total": 100,
"per_page": 20,
"current_page": 1,
"last_page": 4,
"from": 1,
"to": 19,
"_links": {"self": "https://api.voto.vote/{entity+}?page=1",
"prev": "https://api.voto.vote/{entity+}?page=0",
"next": "https://api.voto.vote/{entity+}?page=2"
}
}
}

Create new candidate for application

Creation of candidates is allowed for admin, creator (only in his application) and trustperson (only for his party)

Authorizations:

firebase

path Parameters

applicationId

required

integer <int64>

Numeric ID of the application to get

Request Body schema: application/json

party_id required	integer
user_id required	integer
description	string
district	string
list_place	integer
website	string

Responses

Request samples

Payload

Content type

application/json

{"party_id": 123,
"user_id": 456,
"description": "Example Title",
"district": "Example District",
"list_place": 1,
"website": "https://voto.vote"
}

Response samples

201
400
401
403
500

Content type

application/json

[{"party_id": 123,
"description": "Example Title",
"district": "Example District",
"list_place": 1,
"website": "https://voto.vote",
"id": 123,
"application_id": 789,
"title": "Dr.",
"firstName": "John",
"lastName": "Doe",
"age": 456,
"party_name": "VOP",
"profile_picture": "https://",
"status": 1,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z",
"public": false
}
]

Get single candidate

Fetching a candidate for one application is allowed for everyone.

path Parameters

applicationId required	integer <int64> Numeric ID of the application to get
candidateId required	integer <int64> Numeric ID of the candidate to get

Responses

Response samples

200
404
500

Content type

application/json

{"party_id": 123,
"description": "Example Title",
"district": "Example District",
"list_place": 1,
"website": "https://voto.vote",
"id": 123,
"application_id": 789,
"title": "Dr.",
"firstName": "John",
"lastName": "Doe",
"age": 456,
"party_name": "VOP",
"profile_picture": "https://",
"status": 1,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z",
"public": false
}

Change candidate for application

Changing a candidate for one application is allowed for admin, creator (within his application), trustperson (within his party) and one candidate for itself.

Authorizations:

firebase

path Parameters

applicationId required	integer <int64> Numeric ID of the application to put
candidateId required	integer <int64> Numeric ID of the candidate to put

Request Body schema: application/json

party_id required	integer
user_id required	integer
description	string
district	string
list_place	integer
website	string

Responses

Request samples

Payload

Content type

application/json

{"party_id": 123,
"user_id": 456,
"description": "Example Title",
"district": "Example District",
"list_place": 1,
"website": "https://voto.vote"
}

Response samples

Content type

application/json

[{"party_id": 123,
"description": "Example Title",
"district": "Example District",
"list_place": 1,
"website": "https://voto.vote",
"id": 123,
"application_id": 789,
"title": "Dr.",
"firstName": "John",
"lastName": "Doe",
"age": 456,
"party_name": "VOP",
"profile_picture": "https://",
"status": 1,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z",
"public": false
}
]

Toggle candidate status

Toggle candidates is allowed for admins, creators ( their own application ) and trustpersons ( their own party )

path Parameters

applicationId required	integer <int64> Numeric ID of the VAA
candidateId required	integer <int64> Numeric ID of the candidate

Request Body schema: application/json

status

integer <int64>

Responses

Request samples

Payload

Content type

application/json

{"status": 123
}

Response samples

401
403
404
500

Content type

application/json

{"code": "400",
"message": "Malformed request"
}

Delete candidate object

Deleting a candidate for one application is allowed for admin, creator (within his application), trustperson (within his party) and one candidate for itself.

Authorizations:

firebase

path Parameters

applicationId required	integer <int64> Numeric ID of the application
candidateId required	integer <int64> Numeric ID of the candidate to delete

Responses

Response samples

401
403
404
500

Content type

application/json

{"code": "400",
"message": "Malformed request"
}

Change candidates light profile picture

Changing a candidates light profile picture for one application is allowed for admin, creator (within his application), trustperson (within his party)

Authorizations:

firebase

path Parameters

applicationId required	integer <int64> Numeric ID of the application to put
candidateId required	integer <int64> Numeric ID of the candidate to put
partyId required	integer <int64> Numeric ID of the party to put

Request Body schema: multipart/form-data

candidateId	integer
image	string <binary>

Responses

Response samples

Content type

application/json

{"gender_id": 123,
"party_id": 123,
"firstName": "Max",
"lastName": "Mustermann",
"id": 123,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}

Change candidates profile picture

Changing a candidates profile picture for one application is allowed for admin, creator (within his application), trustperson (within his party) and one candidate for itself.

Authorizations:

firebase

path Parameters

applicationId required	integer <int64> Numeric ID of the application to put
candidateId required	integer <int64> Numeric ID of the candidate to put
partyId required	integer <int64> Numeric ID of the party to put

Request Body schema: multipart/form-data

candidateId	integer
image	string <binary>

Responses

Response samples

Content type

application/json

{"party_id": 123,
"description": "Example Title",
"district": "Example District",
"list_place": 1,
"website": "https://voto.vote",
"id": 123,
"application_id": 789,
"title": "Dr.",
"firstName": "John",
"lastName": "Doe",
"age": 456,
"party_name": "VOP",
"profile_picture": "https://",
"status": 1,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z",
"public": false
}

Change candidates profile picture

Changing a candidates profile picture for one application is allowed for admin, creator (within his application), trustperson (within his party) and one candidate for itself.

Authorizations:

firebase

path Parameters

applicationId required	integer <int64> Numeric ID of the application to put
candidateId required	integer <int64> Numeric ID of the candidate to put

Request Body schema: multipart/form-data

candidateId	integer
image	string <binary>

Responses

Response samples

Content type

application/json

{"party_id": 123,
"description": "Example Title",
"district": "Example District",
"list_place": 1,
"website": "https://voto.vote",
"id": 123,
"application_id": 789,
"title": "Dr.",
"firstName": "John",
"lastName": "Doe",
"age": 456,
"party_name": "VOP",
"profile_picture": "https://",
"status": 1,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z",
"public": false
}

Get votes of a candidate

Fetching a candidates votes for one application is allowed for everyone.

path Parameters

applicationId required	integer <int64> Numeric ID of the application to get
candidateId required	integer <int64> Numeric ID of the candidate to get

Responses

Response samples

200
404
500

Content type

application/json

[{"statement_id": 123,
"application_id": 456,
"value": 75,
"weight": 1,
"explanation": "Lorem ipsum",
"id": 123,
"candidate_id": 456,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}
]

Change candidate votes for application

Changing a candidates votes for one application is allowed for admin and one candidate for itself.

Authorizations:

firebase

path Parameters

applicationId required	integer <int64> Numeric ID of the application to put
candidateId required	integer <int64> Numeric ID of the candidate to put

Request Body schema: application/json

statement_id	integer <int64>
application_id	integer <int64>
value	integer
weight	integer
explanation	string

Responses

Request samples

Payload

Content type

application/json

{"statement_id": 123,
"application_id": 456,
"value": 75,
"weight": 1,
"explanation": "Lorem ipsum"
}

Response samples

Content type

application/json

{"statement_id": 123,
"application_id": 456,
"value": 75,
"weight": 1,
"explanation": "Lorem ipsum",
"id": 123,
"candidate_id": 456,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}

Get parties for application

Fetching parties for one application is allowed for everyone.

path Parameters

applicationId

required

integer <int64>

Numeric ID of the application

query Parameters

limit	integer Default: 20 Example: limit=20 Limits the amount of items in the responsing array. Max results is 100.
page	integer Default: 1 Example: page=5 Sets the page offset
search	string Default: "" Example: search=party detailed name Search for party detailed name
sort	string Default: "name\|asc" Example: sort=location\|desc Sort either ascending or descending all retrieving objects. Always like {attribute}\|{sortingOrder} where sortingOrder can be either `asc` or `desc`

Responses

Response samples

200
404
500

Content type

application/json

{"data": [{"application_id": 123,
"parent_party_id": 456,
"shortcut": "ABC",
"name": "Party name",
"description": "Example party description",
"website": "https://voto.vote",
"id": 123,
"status": 1,
"public": false,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}
],
"pagination": {"total": 100,
"per_page": 20,
"current_page": 1,
"last_page": 4,
"from": 1,
"to": 19,
"_links": {"self": "https://api.voto.vote/{entity+}?page=1",
"prev": "https://api.voto.vote/{entity+}?page=0",
"next": "https://api.voto.vote/{entity+}?page=2"
}
}
}

Create new party for application

Creating parties for one application is allowed for admin and creator (for its own application)

Authorizations:

firebase

path Parameters

applicationId

required

integer <int64>

Numeric ID of the application

Request Body schema: application/json

application_id required	integer
parent_party_id	integer
shortcut required	string
name required	string
description	string
website	string

Responses

Request samples

Payload

Content type

application/json

{"application_id": 123,
"parent_party_id": 456,
"shortcut": "ABC",
"name": "Party name",
"description": "Example party description",
"website": "https://voto.vote"
}

Response samples

201
400
401
403
500

Content type

application/json

[{"application_id": 123,
"parent_party_id": 456,
"shortcut": "ABC",
"name": "Party name",
"description": "Example party description",
"website": "https://voto.vote",
"id": 123,
"status": 1,
"public": false,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}
]

Get single party

Fetching one party for one application by its ID is allowed for everyone.

path Parameters

applicationId required	integer <int64> Numeric ID of the application
partyId required	integer <int64> Numeric ID of the party

Responses

Response samples

200
404
500

Content type

application/json

{"application_id": 123,
"parent_party_id": 456,
"shortcut": "ABC",
"name": "Party name",
"description": "Example party description",
"website": "https://voto.vote",
"id": 123,
"status": 1,
"public": false,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}

Change party for application

Changing a party for one application is allowed for admin, creator and the trustperson for its own party.

Authorizations:

firebase

path Parameters

applicationId required	integer <int64> Numeric ID of the application
partyId required	integer <int64> Numeric ID of the party

Request Body schema: application/json

application_id required	integer
parent_party_id	integer
shortcut required	string
name required	string
description	string
website	string

Responses

Request samples

Payload

Content type

application/json

{"application_id": 123,
"parent_party_id": 456,
"shortcut": "ABC",
"name": "Party name",
"description": "Example party description",
"website": "https://voto.vote"
}

Response samples

Content type

application/json

[{"application_id": 123,
"parent_party_id": 456,
"shortcut": "ABC",
"name": "Party name",
"description": "Example party description",
"website": "https://voto.vote",
"id": 123,
"status": 1,
"public": false,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}
]

Toggle party status

Toggle party is allowed for admins and creators ( their own application )

path Parameters

applicationId required	integer <int64> Numeric ID of the VAA
partyId required	integer <int64> Numeric ID of the party

Request Body schema: application/json

status

integer <int64>

Responses

Request samples

Payload

Content type

application/json

{"status": 123
}

Response samples

401
403
404
500

Content type

application/json

{"code": "400",
"message": "Malformed request"
}

Delete party object

Deleting a party for one application is allowed for admin, creator and trustperson for its own party.

Authorizations:

firebase

path Parameters

applicationId required	integer <int64> Numeric ID of the application
partyId required	integer <int64> Numeric ID of the party

Responses

Response samples

401
403
404
500

Content type

application/json

{"code": "400",
"message": "Malformed request"
}

Change party profile picture

Changing a party logo for one application is allowed for admin, creator (within his application), trustperson (within his party)

Authorizations:

firebase

path Parameters

applicationId required	integer <int64> Numeric ID of the application to put
partyId required	integer <int64> Numeric ID of the party to put

Request Body schema: multipart/form-data

partyId	integer
image	string <binary>

Responses

Response samples

Content type

application/json

{"application_id": 123,
"parent_party_id": 456,
"shortcut": "ABC",
"name": "Party name",
"description": "Example party description",
"website": "https://voto.vote",
"id": 123,
"status": 1,
"public": false,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}

Get candidates for party

Fetching candidates for one party within one application by its ID is allowed for everyone.

path Parameters

applicationId required	integer <int64> Numeric ID of the application
partyId required	integer <int64> Numeric ID of the party

Responses

Response samples

200
404
500

Content type

application/json

[{"party_id": 123,
"description": "Example Title",
"district": "Example District",
"list_place": 1,
"website": "https://voto.vote",
"id": 123,
"application_id": 789,
"title": "Dr.",
"firstName": "John",
"lastName": "Doe",
"age": 456,
"party_name": "VOP",
"profile_picture": "https://",
"status": 1,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z",
"public": false
}
]

Create new candidate for application

Creation of candidates is allowed for admin, creator (only in his application) and trustperson (only for his party)

Authorizations:

firebase

path Parameters

applicationId required	integer <int64> Numeric ID of the application to get
partyId required	integer <int64> Numeric ID of the party

Request Body schema: application/json

party_id required	integer
user_id required	integer
description	string
district	string
list_place	integer
website	string

Responses

Request samples

Payload

Content type

application/json

{"party_id": 123,
"user_id": 456,
"description": "Example Title",
"district": "Example District",
"list_place": 1,
"website": "https://voto.vote"
}

Response samples

201
400
401
403
500

Content type

application/json

[{"party_id": 123,
"description": "Example Title",
"district": "Example District",
"list_place": 1,
"website": "https://voto.vote",
"id": 123,
"application_id": 789,
"title": "Dr.",
"firstName": "John",
"lastName": "Doe",
"age": 456,
"party_name": "VOP",
"profile_picture": "https://",
"status": 1,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z",
"public": false
}
]

Change candidate for application and party

Changing a candidate for one application is allowed for admin, creator (within his application), trustperson (within his party) and one candidate for itself.

Authorizations:

firebase

path Parameters

applicationId required	integer <int64> Numeric ID of the application to put
candidateId required	integer <int64> Numeric ID of the candidate to put
partyId required	integer <int64> Numeric ID of the party to put

Request Body schema: application/json

party_id required	integer
user_id required	integer
description	string
district	string
list_place	integer
website	string

Responses

Request samples

Payload

Content type

application/json

{"party_id": 123,
"user_id": 456,
"description": "Example Title",
"district": "Example District",
"list_place": 1,
"website": "https://voto.vote"
}

Response samples

Content type

application/json

[{"party_id": 123,
"description": "Example Title",
"district": "Example District",
"list_place": 1,
"website": "https://voto.vote",
"id": 123,
"application_id": 789,
"title": "Dr.",
"firstName": "John",
"lastName": "Doe",
"age": 456,
"party_name": "VOP",
"profile_picture": "https://",
"status": 1,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z",
"public": false
}
]

Toggle candidate status

Toggle candidates is allowed for admins, creators ( their own application ) and trustpersons ( their own party )

path Parameters

applicationId required	integer <int64> Numeric ID of the VAA
candidateId required	integer <int64> Numeric ID of the candidate
partyId required	integer <int64> Numeric ID of the party to put

Request Body schema: application/json

status

integer <int64>

Responses

Request samples

Payload

Content type

application/json

{"status": 123
}

Response samples

401
403
404
500

Content type

application/json

{"code": "400",
"message": "Malformed request"
}

Delete candidate object

Deleting a candidate for one application is allowed for admin, creator (within his application), trustperson (within his party) and one candidate for itself.

Authorizations:

firebase

path Parameters

applicationId required	integer <int64> Numeric ID of the application
candidateId required	integer <int64> Numeric ID of the candidate to delete
partyId required	integer <int64> Numeric ID of the party to put

Responses

Response samples

401
403
404
500

Content type

application/json

{"code": "400",
"message": "Malformed request"
}

Get candidates light for party

Fetching candidates light for one party within one application by its ID is allowed for everyone.

path Parameters

applicationId required	integer <int64> Numeric ID of the application
partyId required	integer <int64> Numeric ID of the party

Responses

Response samples

200
404
500

Content type

application/json

[{ }
]

Create new candidate for application

Creation of candidates is allowed for admin, creator (only in his application) and trustperson (only for his party)

Authorizations:

firebase

path Parameters

applicationId required	integer <int64> Numeric ID of the application to get
partyId required	integer <int64> Numeric ID of the party

Request Body schema: application/json

gender_id required	integer
party_id required	integer
firstName required	string Firstname of candidate light. Can also contain title as prefix
lastName required	string Lastname of candidate light

Responses

Request samples

Payload

Content type

application/json

{"gender_id": 123,
"party_id": 123,
"firstName": "Max",
"lastName": "Mustermann"
}

Response samples

201
400
401
403
500

Content type

application/json

[{"gender_id": 123,
"party_id": 123,
"firstName": "Max",
"lastName": "Mustermann",
"id": 123,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}
]

Get candidate light for application and party

Get a candidate light for one application is allowed for admin, creator (within his application), trustperson (within his party)

Authorizations:

firebase

path Parameters

applicationId required	integer <int64> Numeric ID of the application to get
candidateId required	integer <int64> Numeric ID of the candidate to get
partyId required	integer <int64> Numeric ID of the party to get

Responses

Response samples

Content type

application/json

[{"gender_id": 123,
"party_id": 123,
"firstName": "Max",
"lastName": "Mustermann",
"id": 123,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}
]

Change candidate for application and party

Changing a candidate for one application is allowed for admin, creator (within his application), trustperson (within his party)

Authorizations:

firebase

path Parameters

applicationId required	integer <int64> Numeric ID of the application to put
candidateId required	integer <int64> Numeric ID of the candidate to put
partyId required	integer <int64> Numeric ID of the party to put

Request Body schema: application/json

gender_id required	integer
party_id required	integer
firstName required	string Firstname of candidate light. Can also contain title as prefix
lastName required	string Lastname of candidate light

Responses

Request samples

Payload

Content type

application/json

{"gender_id": 123,
"party_id": 123,
"firstName": "Max",
"lastName": "Mustermann"
}

Response samples

Content type

application/json

[{"gender_id": 123,
"party_id": 123,
"firstName": "Max",
"lastName": "Mustermann",
"id": 123,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}
]

Delete candidate object

Deleting a candidate light for one application is allowed for admin, creator (within his application), trustperson (within his party)

Authorizations:

firebase

path Parameters

applicationId required	integer <int64> Numeric ID of the application
candidateId required	integer <int64> Numeric ID of the candidate to delete
partyId required	integer <int64> Numeric ID of the party to delete

Responses

Response samples

401
403
404
500

Content type

application/json

{"code": "400",
"message": "Malformed request"
}

Get votes of a party

Fetching votes for one specific party is allowed for everyone.

path Parameters

applicationId required	integer <int64> Numeric ID of the election to get
partyId required	integer <int64> Numeric ID of the party to get

Responses

Response samples

200
404
500

Content type

application/json

[{"statement_id": 123,
"application_id": 456,
"value": 75,
"weight": 1,
"explanation": "Lorem ipsum",
"id": 123,
"party_id": 456,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}
]

Change party votes for application

Changing votes for one specific party is only allowed for trustperson (for its own party)

Authorizations:

firebase

path Parameters

applicationId required	integer <int64> Numeric ID of the application to put
partyId required	integer <int64> Numeric ID of the partyId to put

Request Body schema: application/json

statement_id	integer <int64>
application_id	integer <int64>
value	integer
weight	integer
explanation	string

Responses

Request samples

Payload

Content type

application/json

{"statement_id": 123,
"application_id": 456,
"value": 75,
"weight": 1,
"explanation": "Lorem ipsum"
}

Response samples

Content type

application/json

{"statement_id": 123,
"application_id": 456,
"value": 75,
"weight": 1,
"explanation": "Lorem ipsum",
"id": 123,
"party_id": 456,
"created_at": "2021-10-05T06:00:00.000Z",
"updated_at": "2021-10-05T06:00:00.000Z"
}

Action

Custom VOTO action

Send action request to trigger custom action

Authorizations:

firebase

Request Body schema: application/json

action	string Enum: "ActionTypeChangeMail" "ActionTypeChangePassword" "ActionFinalizeAppTheses" "ActionFinalizePartyTheses" "ActionFinalizeCandidateTheses" "ActionCandidateFirstLogin"
id	integer Must be the applicationId/partyId

Responses

Request samples

Payload

Content type

application/json

{"action": "ActionTypeChangeMail",
"id": 123
}

Response samples

400
401
403
500

Content type

application/json

{"code": "400",
"message": "Malformed request"
}

Custom mail VOTO action

Send action request to trigger custom mail sending

Authorizations:

firebase

Request Body schema: application/json

AddressType	string Enum: "AddressTypePersonalized" "AddressTypeCommon"
Subject	string The subject of the mail
Title	string Title within the mail
Call2Action	string Some call to action ( text of the button )
HTML	string html string of the mail content
DryRun	boolean Test only mode - not sending except to you
Apps	Array of integers <int64>
	object

Responses

Request samples

Payload

Content type

application/json

{"AddressType": "AddressTypePersonalized",
"Subject": "string",
"Title": "string",
"Call2Action": "string",
"HTML": "string",
"DryRun": true,
"Apps": [0
],
"TargetStatus": {"TargetTrustPersonStatus": 0,
"TargetCandidateStatus": 0
}
}

Response samples

400
401
403
500

Content type

application/json

{"code": "400",
"message": "Malformed request"
}

Finalize app theses

Send action request to finalize app theses

Authorizations:

firebase

path Parameters

applicationId

required

integer <int64>

Numeric ID of the VAA

Responses

Response samples

400
401
403
500

Content type

application/json

{"code": "400",
"message": "Malformed request"
}

Finalize party theses

Send action request to finalize party theses

Authorizations:

firebase

path Parameters

partyId

required

integer <int64>

Numeric ID of the party

Responses

Response samples

400
401
403
500

Content type

application/json

{"code": "400",
"message": "Malformed request"
}

Finalize party theses

Send action request to finalize candidate theses

Authorizations:

firebase

path Parameters

candidateId

required

integer <int64>

Numeric ID of the candidate

Responses

Response samples

400
401
403
500

Content type

application/json

{"code": "400",
"message": "Malformed request"
}

Invite admins

Send action request to invite admins

Authorizations:

firebase

Request Body schema: application/json

id	integer Must be the candidate/trustperson/creator/admin ID
	object

Responses

Request samples

Payload

Content type

application/json

{"id": 123,
"Mailoptions": {"formats": "string"
}
}

Response samples

400
401
403
500

Content type

application/json

{"code": "400",
"message": "Malformed request"
}

Invite creator

Send action request to invite creator

Authorizations:

firebase

path Parameters

applicationId

required

integer <int64>

Numeric ID of the VAA

Request Body schema: application/json

id	integer Must be the candidate/trustperson/creator/admin ID
	object

Responses

Request samples

Payload

Content type

application/json

{"id": 123,
"Mailoptions": {"formats": "string"
}
}

Response samples

400
401
403
500

Content type

application/json

{"code": "400",
"message": "Malformed request"
}

Invite trustperson

Send action request to invite TrustPersons

Authorizations:

firebase

path Parameters

applicationId

required

integer <int64>

Numeric ID of the VAA

Request Body schema: application/json

id	integer Must be the candidate/trustperson/creator/admin ID
	object

Responses

Request samples

Payload

Content type

application/json

{"id": 123,
"Mailoptions": {"formats": "string"
}
}

Response samples

400
401
403
500

Content type

application/json

{"code": "400",
"message": "Malformed request"
}

Invite candidates

Send action request to invite candidates

Authorizations:

firebase

path Parameters

applicationId required	integer <int64> Numeric ID of the VAA
partyId required	integer <int64> Numeric ID of the party

Request Body schema: application/json

id	integer Must be the candidate/trustperson/creator/admin ID
	object

Responses

Request samples

Payload

Content type

application/json

{"id": 123,
"Mailoptions": {"formats": "string"
}
}

Response samples

400
401
403
500

Content type

application/json

{"code": "400",
"message": "Malformed request"
}

Calculate standard deviation for app

Send action request to calculate standard deviation of answered theses of matches

Authorizations:

firebase

path Parameters

applicationId

required

integer <int64>

Numeric ID of the VAA

Responses

Response samples

200
400
401
403
500

Content type

application/json

{"Candidates": [{"Value": 12.2,
"StatementId": 123,
"Votes": 123
}
],
"Parties": [{"Value": 12.2,
"StatementId": 123,
"Votes": 123
}
]
}

Metrics

Get global voto votes

Get global voto votes count

Responses

Response samples

200
400

Content type

application/json

{"votes": 204604
}

Get voto metrics for one instance

Get global voto votes count

path Parameters

applicationId

required

integer <int64>

Numeric ID of the VAA

Responses

Response samples

200
400

Content type

application/json

{"votes": {"votes": 204604
},
"voto_started": 100000,
"voto_finished": 99999,
"history": [{"Votes": 204604,
"Timestamp": 1662595217
}
]
}
